GC-M3A آلة حافة شريط المراتب
GC-M3A
توصيل
FOB，EXW
من أجل الحد الأدنى
1 جلس
القدرة على التوريد
100جلس / الشهر
المكان الأصلي للإنتاج
NINGBO
كمية
Main application & performance:
With the table is supported by high-strength independent bearing, the machines working table becomes more stable. An inside hidden-power-supply column makes the machine have no special requirement on installation space.
Technical data:
| Turning speed auto slow down | YES |
|---|---|
| Sewing head | Lock stitch, Chain stitch |
| Working angle of the sewing head | 35° - 55° |
| Sewing thickness range of mattress | 50-280mm, 150-400mm, 250-500mm |
| Lifting of working table | electric |
| Carriage speed (m/min) | 5.5-16 |
| Size of the work table | 1400×1950mm, 1550×2050mm, 1800×1950mm |
| Sewing head speed (r/min) | 1100 ~ 3000 |
| Motor type | Single-phase / three-phase motor |
| Total power | 1.12kw |
