Main application and performance:The machine is one of new-style edge closing machines .Its working table have only two transmission belts, transports as one set. It is controled by PLC,and it have functions of travelling, cornerring and flipping automatically .The functions of automatic adjustment improve the sewing speed and quality. the stable and reliable adjustmen mechanism make the changes of product specifications be more convenient and efficient.It is a perfect equipment to manufacture mattress. Technical data:| Sewing head type: | chain stitch |
|---|
| Sewing head lifting range: | 0 - 240mm |
|---|
| Tilting angle of Sewing head: | 25 - 65 |
|---|
| Table conveyer belt speed: | 10 - 14m/min |
|---|
| Available mattress thickness: | 50 – 400mm |
|---|
| Sewing head speed: | 1642—2740r/min |
|---|
| Production efficiency: | 16—20 units/hour |
|---|
| Motor power: | 2.8KW |
|---|
| Air pressure: | 0.6—0.8（Mpa） |
|---|
| Working table size: | L3750×W1980mmMain application and performance:The machine is one of new-style edge closing machines .Its working table have only two transmission belts, transports as one set. It is controled by PLC,and it have functions of travelling, cornerring and flipping automatically .The functions of automatic adjustment improve the sewing speed and quality. the stable and reliable adjustmen mechanism make the changes of product specifications be more convenient and efficient.It is a perfect equipment to manufacture mattress. Technical data:| Sewing head type: | chain stitch |
|---|
| Sewing head lifting range: | 0 - 240mm |
|---|
| Tilting angle of Sewing head: | 25 - 65 |
|---|
| Table conveyer belt speed: | 10 - 14m/min |
|---|
| Available mattress thickness: | 50 – 400mm |
|---|
| Sewing head speed: | 1642—2740r/min |
|---|
| Production efficiency: | 16—20 units/hour |
|---|
| Motor power: | 2.8KW |
|---|
| Air pressure: | 0.6—0.8（Mpa） |
|---|
| Working table size: | L3750×W1980mm |
|---|
|
|
|---|
|
