Machine de bord de bande de matelas GC-M6

GC-M6

Livraison

FOB,EXW,CIF,CFR

commande minimum

1 ensemble

Disponibilité

100ensemble / Mois

Lieu d'origine

NINGBO

Quantité

envoyer le contact

Ajouter au panier

Model GC-M6 Tape Edge Machine

Model GC-M6 tape edge machine is mainly used for sewing mattress. A precision guide track is equipped on its support frame, which makes the walking carriage move accurately and the machine run smoothly. At the same time, its walking carriage running, sewing head tilting angle and working table height are controlled by electricity. This feature makes operation more convenient. It is a perfect equipment for manufacturing high-class mattress.

Technical data:

Sewing head type	Chain stitch
Sewing head lifting range	0-200mm
Sewing head motor rotary speed	Max 3065r/min
Carriage speed:	13.6(m/min)
Tilting angle of sewing head:	35°~ 55°
Sewing mattress thickness:	50~500mm
Table lifting range:	0~400(mm)
Carriage clutching mode	Electromagnet clutching
Working table size:	2000×1600(mm), 2000×1800(mm)
Productivity	10-20pcs/h
Motor power:	1.65(kw)
