borde de la cinta de la máquina del colchón

Máquina de borde de cinta de colchón GC-M6

GC-M6
Entrega
FOB,EXW,CIF,CFR
pedido mínimo
1 conjunto
Disponibilidad
100conjunto / El
Lugar original de origen
NINGBO
Cantidad
enviar contacto
Añadir al carrito

Model GC-M6 Tape Edge Machine

Model GC-M6 tape edge machine is mainly used for sewing mattress. A precision guide track is equipped on its support frame, which makes the walking carriage move accurately and the machine run smoothly. At the same time, its walking carriage running, sewing head tilting angle and working table height are controlled by electricity. This feature makes operation more convenient. It is a perfect equipment for manufacturing high-class mattress.

Technical data:

Sewing head typeChain stitch
Sewing head lifting range0-200mm
Sewing head motor rotary speedMax 3065r/min
Carriage speed:13.6(m/min)
Tilting angle of sewing head:35°~ 55°
Sewing mattress thickness:50~500mm
Table lifting range:0~400(mm)
Carriage clutching modeElectromagnet clutching
Working table size:2000×1600(mm), 2000×1800(mm)
Productivity10-20pcs/h
Motor power:1.65(kw)
